This application is under active development and likely to change further before stabilizing.
ITS (Image Transform Service) performs transformations and optimizations on images by accepting transform requests in the form of query strings.
There are three varieties of crop -- default, focal and smart crop.
The default crops the input image about the center of the image. The image will be resized down first, depending on the lesser dimension of the image.
To use this crop, use the crop
keyword with two arguments split by x's:
Where:
- crop -- indicates that ITS should perform a crop and use the middle of the image as the focal point for the crop.
- WW -- a numerical pixel value representing the desired width of the output image
- HH -- a numerical pixel value representing the desired height of the output image
Original Image:
https://image.pbs.org/video-assets/5jJewwH-asset-mezzanine-16x9-esGHBDK.png
Applying crop
:
https://image.pbs.org/video-assets/5jJewwH-asset-mezzanine-16x9-esGHBDK.png?crop=700x200
Focal crop returns an image focused around a user-specified point in the original image of a user-specified size. To use this crop, utilize the crop
keyword with four arguments split by x's:
Where:
- crop -- indicates that ITS should perform a crop
- WW -- a numerical pixel value representing the desired width of the output image
- HH -- a numerical pixel value representing the desired height of the output image
- XX -- the x axis of the focal point, represented as a percentage value of the width of the original picture
- YY -- the y axis of the focal point, represented as a percentage value of the height of the original picture
Original Image:
https://image.pbs.org/test/GmtpBa4-asset-mezzanine-16x9-Uu2CpNc.png
Applying crop
with four parameters:
https://image.pbs.org/test/GmtpBa4-asset-mezzanine-16x9-Uu2CpNc.png?crop=500x400x90x10
Smart crop returns an image focused around a user-specified point in the original image of a user-specified size. To use this crop, the input image filename must end in _focus-XXxYY.ext
, and then you can use the crop
keyword with two arguments split by x's:
https://image.pbs.org/path/to/file_focus-XXxYY.ext?crop=WWxHH
Where:
- XX -- the x axis of the focal point, represented as a percentage value of the height of the original picture
- YY -- the y axis of the focal point, represented as a percentage value of the height of the original picture
- crop -- indicates that ITS should perform a crop
- WW -- a numerical pixel value representing the desired width of the output image
- HH -- a numerical pixel value representing the desired height of the output image
Original Image:
https://image.pbs.org/test/Sjk2Eqs-asset-mezzanine-16x9-0gsKw4z_focus-90x10.png
Applying crop
:
https://image.pbs.org/test/Sjk2Eqs-asset-mezzanine-16x9-0gsKw4z_focus-90x10.png?crop=300x400
Overlay returns the input image with the specified overlay image placed on top of it. The overlay is placed in the top left corner. To use overlay, use the overlay keyword:
API_URL/<file_path/filename.ext>?overlay=<overlay_img_path>
Where:
- overlay -- indicates that ITS should put an overlay on the input image
- overlay_img_path -- path to the overlay (optionally, can be a keyword a keyword in the OVERLAYS dictionary in settings)
Resize returns a resized version of the original image without distortion of the aspect ratio. To use it, use the resize
keyword with two arguments split by x's:
Where:
- resize -- indicates that ITS should perform a resize transform
- WW -- a numerical pixel value representing the desired width of the output image
- HH -- a numerical pixel value representing the desired height of the output image
Resize has an option to not scale up, if the provided width and/or height is larger than those of the image. Use the resize
keyword, but add a comma and a third argument no-scale-up
:
https://image.pbs.org/path/to/file.jpg?resize=WWxHH,no-scale-up
Or, with missing height:
https://image.pbs.org/path/to/file.jpg?resize=WWx,no-scale-up
Or, with missing width:
https://image.pbs.org/path/to/file.jpg?resize=xHH,no-scale-up
Note: Resizing to a larger size isn’t recommended, as it will compromise image quality.
Note: Inputing a single value (either an expected width size or an expected height size followed by an 'x') is also supported.
Example
Original Image:
https://image.pbs.org/video-assets/GTdD9Rq-asset-mezzanine-16x9-d3h7qCm.jpg
With resize
applied:
https://image.pbs.org/video-assets/GTdD9Rq-asset-mezzanine-16x9-d3h7qCm.jpg?resize=400x200
With resize
applied and only a width supplied:
https://image.pbs.org/video-assets/GTdD9Rq-asset-mezzanine-16x9-d3h7qCm.jpg?resize=400x
Format returns the input image in the specified type, rather than being left as the original image’s type. It currently supports conversion to JPG, PNG, and WEBP. To use it, use the format
keyword with the file extension as an argument:
Where:
- format -- indicates that ITS should perform a format transform
- ext -- the requested output type. Can only be
jpg
,png
,webp
orauto
(auto
will examine the image and return either a jpg or png depending on the image's complexity) - quality -- optional, allows user to specify the quality that they would like the output image to have. Currently, this parameter only works with the
jpg
format. Accepts a multiple 10 up to 100.
Example
Original Image:
https://image.pbs.org/test/7Sy3rBL-asset-mezzanine-16x9-xMYNIn3.jpg
Image as a PNG:
https://image.pbs.org/test/7Sy3rBL-asset-mezzanine-16x9-xMYNIn3.jpg?format=png
Image as a JPG with a quality of 20:
https://image.pbs.org/test/7Sy3rBL-asset-mezzanine-16x9-xMYNIn3.jpg?quality=20
Blur returns an image subject to a Gaussian Blur. To use it, use the blur
keyword with an integer (for the pixel radius of the blur) as an argument:
Where:
- blur -- indicates that ITS should perform a blur transform
- radius -- an integer pixel value representing the desired radius of the blur effect
Example
Original Image:
https://image.pbs.org/test/7Sy3rBL-asset-mezzanine-16x9-xMYNIn3.jpg
Blurred Image:
https://image.pbs.org/test/7Sy3rBL-asset-mezzanine-16x9-xMYNIn3.jpg?blur=10
All of the transforms described above can be combined into one query by separating them with &
.
An image cropped to 600x300px, changed to a PNG:
https://image.pbs.org/test/nBVLq44-asset-mezzanine-16x9-p0bSjVY.jpg?crop=600x300&format=png
Here are some commands you can run while developing locally.
Run tests:
docker-compose build server
docker-compose run server pipenv run pytest its/tests
Note: Clear your local environment variables before running tests.
Run development server:
docker-compose up --build
Run autoformatter for python code:
docker-compose run server ./scripts/docker/server/format.sh
Run static type checking:
docker-compose run server ./scripts/docker/server/type-check.sh
Apply autogenerated type annotations:
docker-compose run server pipenv run pyannotate --write --type-info ./type_info.json its/path_to_file.py
Build and publish docker image
Note: you have to authenticate to Docker Hub first.
./scripts/do publish
